Description

H_4xDVI Input Card

Video input card for the controllers of the H series.

HDMI 1.3 Input:

• 2x HDMI 1.3:
• Supported resolution per input: Min. 800×600@60Hz, Max. 2048×1152@60Hz
• Custom EDIDs:
• Max width: 2560 pixels (2560×972@60Hz)
• Max height: 2560 pixels (884×2560@60Hz)
• HDCP 1.4 compatible

HDMI 1.4 Input:

• 2x HDMI 1.4:
• Supported resolution per input: Min. 800×600@60Hz, Max. 2048×1152@60Hz
• Custom EDIDs:
• Max width: 2560 pixels (2560×972@60Hz)
• Max height: 2560 pixels (884×2560@60Hz)
• HDCP 1.4 compatible

HDMI 1.4 Input (Ports 2 & 4):

• Ports 2 and 4 are used for input, while Ports 1 and 3 are unavailable.
• Supported resolution per input: Max. 3840×1080@60Hz
• Custom EDIDs:
• Max width: 4096 pixels (4096×1124@60Hz)
• Max height: 4095 pixels (1014×4095@60Hz)
• HDCP 1.4 compatible

Additional Specifications:

• Supports 10-bit video sources
• Does not support interlaced signals
