PIXELHUE U3 Technical Specifications

Physical Specifications

• Dimensions (with handles, rack ears & rack mount): W 1100 × D 674.8 × H 388.8 mm (43.3 × 26.6 × 15.3 inches)
• Please refer to the dimension diagram for more details.
• Product Net Weight: 32 kg / 70.5 lbs (Net weight), 84 kg / 185.2 lbs (With Accessories and flight case)
• Noise on Average (@1, 0.75m height): Front: 50 dB, Rear: 50 dB

Electrical Parameters

• Dual Backup Power Supply
• Power Connector: AC100 V‒240 V, 50/60 Hz
• Max Power Consumption: 115 W
• Average Power Consumption: 100 W

Operating Conditions

• Temperature: 0°C to 50°C
• Humidity: 0% RH to 85% RH, non-condensing

Packing Information

• 3 × Power cords
• 2 × DVI cables
• 1 × CAT5e Ethernet cable
• 1 × T-Handle Hex Key
• 1 × Dust cover
• 1 × Flight Case
• 1 × Certificate of Approval
• 1 × Customer Letter
• 1 × Quick Start Guide
• 1 × Safety Manual
